The industry-leading Active-Active storage architecture is adopted to achieve load balancing between controllers, eliminate controller performance bottleneck, and improve  system performance.

The storage system supports the configuration of volumes with or without ownership. The volume without ownership is combined with self-developed multi-path software to achieve load balancing of multiple controllers and better system performance.

The system adopts full redundancy architecture and modular design, with all core components being fully redundant to eliminate single point of failure and achieve high availability of the storage system.

The core components are supported by PCIe4.0, which doubles the link bandwidth of the whole machine and doubles the IOPS of the storage system.

Supports 2U12 and 2U25 specification controller enclosures, flexible combination of SAS SSD, SAS HDD and other hard disks, to provide higher performance and larger capacity data storage experience.

Supports 2U12,2U25,3U48 SAS protocol disk enclosures and 2U25 NVMe protocol disk enclosure, which can be cascaded vertically in multiple levels as required to flexibly expand storage space and reduce investment costs.

Intelligent compression, the maximum compression ratio can reach 5:1, significantly improve the efficiency of space utilization; intelligent deduplication, to achieve efficient deletion of duplicate data, higher return on equipment investment.

Supports the simultaneous use of IP-SAN, FC-SAN, RoCE and other protocols. A set of storage supports multiple application platforms, and the system architecture is simpler to work.

There are multiple data redundancy protection modes, local support for write-time replication, snapshot, clone and incremental backup; support for intelligent  metro, remote replication, 3DC and other disaster recovery solutions to ensure business continuity and apply high availability.

Intelligent distributed RAID technology, redundant data  blocks can be quickly restored, data blocks and hot backup blocks are distributed on all hard disks. After a bad disk appears, all hard disks participate in reconstruction, and the data  reconstruction time is shortened to minute level with reducing the risk of RAID failure and enhancing system  reliability.

Intelligent data encryption, effectively prevent data from being illegally accessed or leaked  in storage, transmission, to ensure the security and integrity of data; intelligent data erase, one-click intelligent erase of  obsolete data, ensure  secure use of critical and sensitive data.

Supports online  hardware expansion, online firmware upgrade, and online system maintenance to ensure the continuity of  the service system; supports continuous BBU power failure protection for 2 times, and business is not interrupted within 2S~5S, easily respond to risks such as power outages at data centers.

Graphical interface design: Provides online monitoring of storage performance, capacity, and system status, as well as DMP maintenance wizard for fault  events.

Efficient configuration management: Supports GUI and CLI management operations, supports configuration of multiple role permission control, and realizes efficient management of storage data access permissions.

Intelligent heterogeneous virtualization, heterogeneous storage devices of mainstream  storage vendors eliminate platform differences and realize efficient reuse of storage devices; at the same time, enhance data mobility and eliminate data islands, and the unified management of resources is simple and efficient.
